CryoMass Refinement System
CryoMass Refinement System
The CryoMass Refinement System uses patented technology to instantly freeze plant material and fully separate delicate trichomes from biomass. The rapid freezing and gentle separation processes maintain trichome integrity, preventing loss or change of cannabinoid and terpene profiles.
This unique patented technology can preserve greater than 90% of cannabinoids and, by removing non-cannabinoid and -terpene containing material, reduce the volume of end-product up to 80% relative to the volume of input starting material. The resulting “cryogenic sift” is a highly pure, dry, and stable trichome sift ready for storage or refinement with solventless or solvent processes.
The New World Standard
Bringing never before seen efficiencies and options to cannabis and hemp operators.
Eliminate Drying and Trimming
Process fresh whole plant straight from the field and reduce days of work
Green Process
Minimal energy usage and no organic solvents. Minimal ecological footprint
Industrial Capacity
Process up to 1,300 lbs/600,000 grams of fresh biomass per hour
Biomass Versatility
Process wet or dry, fresh frozen, whole plant, cured flower, and trim
Increase Extraction Throughput of Your Lab
The Cryomass Refinement System drastically increases feedstock cannabinoid and terpene concentration for solvent-based extraction by up to 4X, due to the targeted separation of plant matter from cannabinoid- and terpene-containing trichomes.
Safety In Mind
C1D2 Enclosures Available
Engineered to EU GMP Compliance
Built out of 316L Stainless Steel
Easy To Use
Clean-In-Place Ready
Continuous Production Capacity
Programmed & Automatic Operation
Safety In Mind
C1D2 Enclosures Available
Engineered to EU GMP Compliance
Built out of 316L Stainless Steel
Easy To Use
Clean-In-Place Ready
Continuous Production Capacity
Programmed & Automatic Operation
The CryoMass Solution
Specifications
Compliance
- Components Compliant to:
- UL 508/CSA C22.2 No. 142
- UL 508/CSA C22.2 No. 274
- UL 429/CSA-C22.2 No. 139
- Designed for Clean-In-Place (CIP)
- Designed to meet EudraLex/FDA cGMP Standards
Materials
- 316L Stainless Steel
- Surface Finishes – 32Ra or Better
- Welding Type – Certified TIG
Dimensions
- 10’H X8’W X 20’L
- Approx. Net Weight: 7,000 lbs
- Available in C1D2 20ft Container
Monitoring & Control Systems
- Flow Control System – Automatic proportional valves
- Security System – PLC Siemens / Carel
- Data Logger System – PLC Siemens / Carel
- Remote Monitoring & Control System of Variables – available independent telecommunications module with its own network
- Security System for Atmosphere Composition Control – sensor system for online compound analysis
Connectivity
- Electrical Connection – 460VAC 3~ 60Hz 75A
- Electrical Safety Systems – Overvoltage protection systems
- Complementary Electrical Systems – After a power outage, it returns to the process where it was before
A Team To Trust
The Team at CryoMass Technologies is committed to providing our customers with the most revolutionary agricultural technology for harvesting, drying, and refining. Our team of industry-leading experts utilizes our design, engineering, manufacturing, and extraction expertise to ensure that our products perform to the highest of standards. Helping our customers reach their goals is our number one priority!
